6SL3210-1PH31-4AL0 Overview
6SL3210-1PH31-4AL0 is a Siemens SINAMICS G120 PM240-2 power module with integrated line filter and braking chopper. It is rated for demanding three-phase variable-speed drive applications. Match the control unit, output rating, incoming supply and cabinet thermal design before replacement.
Technical and Ordering Information
| Drive family | SINAMICS G120 |
|---|---|
| Power module | PM240-2 with line filter and braking chopper |
| Supply voltage | 3 AC 500 to 690 V |
| High-overload output | 110 kW |
| Low-overload output | 132 kW |
| Frame size | F |
| Protection | IP20 |
| Dimensions | 708 × 305 × 357 mm |
| Weight | 65 kg |
| Warranty | 1 year |
Buyer and Engineering Checks
- Confirm 500–690 V input range, required HO/LO power rating and frame size F.
- Match fitted control unit, motor data, braking duty and line-side protection.
- Check cabinet clearances, cooling airflow and all power-terminal connections.
Quotation Support
Send 6SL3210-1PH31-4AL0, quantity and destination for current stock, condition, packing and delivery confirmation.
