Products Description
The 330130-080-12-CN extension cable provides robust connectivity between field probes and proximitor sensors, ensuring consistent data flow for machinery condition monitoring. Its industrial-grade design preserves signal fidelity across extended runs, and the cable resists vibration, thermal extremes, and electrical disturbances common in heavy machinery environments.
Functional Role / System Position
Installed inline with the 3300 XL 8 mm system, this cable transmits sensor signals to the monitoring or control equipment without altering signal characteristics. It acts as a high-integrity link within the measurement chain, supporting accurate vibration and displacement detection in rotating machinery.
Key Features / Functional Capabilities
- Signal Transmission Integrity: Maintains accurate electrical characteristics to avoid measurement drift
- Electromagnetic Protection: Multi-layer shielding prevents interference from industrial noise sources
- Continuous Operation: Designed to operate reliably under sustained vibration and temperature variations
- System Interoperability: Compatible with all 3300 XL Proximitor configurations for seamless integration
- Mechanical Durability: Reinforced outer jacket and connectors resist abrasion, bending, and field handling stress
- Installation Efficiency: Modular connectors allow rapid field replacement and minimize maintenance downtime
Application Areas / Typical Use Cases
- Extending probe connections in turbine, pump, or compressor monitoring systems
- Retrofitting existing 3300 XL installations for enhanced reach
- Supporting predictive maintenance programs requiring accurate signal acquisition
- Industrial facilities with significant EMI and vibration challenges
- Locations requiring robust, long-term continuous signal transmission
Parameter Table
| Parameter | Specification |
|---|---|
| Cable Length Option (A) | 8.0 m (26.2 ft) |
| Coupling Interface (Connector Type) | ClickLoc, secured inline connection |
| Electrical Path / Signal Transmission | Maintains calibration integrity across full length |
| Cable & Connector Configuration (B) | Standard cable with connector protector |
| Compliance & Certification (C) | CSA, ATEX, IECEx approvals |
| System Compatibility | 3300 XL 8 mm Proximity Transducer System |
| Shielding | Multi-layer EMI suppression |
| Protective Jacket Material | Industrial polymer for chemical and abrasion resistance |
| Operational Temperature | -35°C to +177°C |
| Storage Temperature | -51°C to +177°C |
| Installation Method | Inline between probe and proximitor sensor |
| Environmental Resistance | Oil, dust, moisture, and mechanical stress resistant |
Contact Information
For pricing, availability, or technical consultation regarding this model, please contact our sales team:
【Sales Manager】
Silver
【WhatsApp】
+86-18020714492
【Email】
sales1@askplc.com
【WeChat】
+86-18020714492
FAQ
Q1: How does this cable maintain measurement accuracy?
It preserves the electrical characteristics of the system link, preventing signal distortion during transmission.
Q2: Can it withstand harsh industrial conditions?
Yes, the cable's shielding and rugged jacket allow operation under vibration, temperature extremes, and dust exposure.
Q3: Which 3300 XL components are compatible?
It integrates with all 8 mm Proximitor sensors and probes within the 3300 XL platform.
Q4: What approvals does this model have?
The cable meets CSA, ATEX, and IECEx standards for industrial compliance.
Q5: Is field replacement straightforward?
Yes, its modular connectors allow quick installation or replacement without disturbing existing sensor setups.
