Products Description
The ABB DSBC110 57310256-E is a Profibus-DP Bus Termination Module (also referred to as a bus matching module or repeater board) designed specifically for the ABB Advant OCS and System 800xA legacy platform bus systems .
As a physical layer key component for Profibus-DP networks, this module provides built-in terminal resistance at the beginning and end of linear bus segments to suppress signal reflections and ensure stable communication. When the main controller is located at the bus endpoint, the DSBC110 must be installed on the bus connector to match the cable impedance, preventing data packet collisions and bit errors caused by impedance discontinuities .
This product serves as a critical spare part for the maintenance, expansion, and troubleshooting of legacy ABB distributed control systems, addressing common issues such as communication fluctuations, bit errors, and network interruptions .
Contact Information
If you want to request a quote, technical support, or purchase this ABB DSBC110 57310256-E probe, please contact us:
Manager：Winnie
Email：sales7@askplc.com
WhatsApp：+86 180 2071 6847
Technical Specifications
| Parameter | Specification |
| Model | DSBC110 57310256-E |
| Product Type | Profibus-DP Bus Termination Module |
| Category | Advant OCS Bus Termination / Matching Module |
| Core Function | Bus impedance matching, signal reflection suppression |
| Communication Protocol | Profibus-DP |
| Baud Rate | 9.6 kbps – 12 Mbps |
| Termination Resistance | 220 Ω |
| Supply Voltage | 24 V DC |
| Operating Temperature | 0°C to +55°C (some sources: -25°C to +60°C) |
| Protection Rating | IP20 (control cabinet installation) |
| Dimensions (approx.) | 254 × 25 × 254 mm or 86.5×35×80mm |
| Weight | 0.25 – 0.4 kg |
| Country of Origin | Sweden (SE) |
| Compatibility | ABB Advant OCS, System 800xA legacy bus systems |
Key Design Features & Advantages
Profibus-DP Standard Compliance – Fully compliant with Profibus-DP bus standards, supporting baud rates from 9.6 kbps to 12 Mbps for broad compatibility with existing industrial networks .
Effective Signal Reflection Suppression – Provides built-in terminal resistance at linear bus endpoints to match cable impedance, eliminating data packet collisions and communication bit errors caused by signal reflections .
Critical Spare Part for Legacy Systems – An essential maintenance component for ABB Advant OCS and older DCS systems, ensuring continued operation and reliability of legacy automation infrastructure .
Plug-and-Play Installation – Designed for simple installation on the bus connector at the controller endpoint, requiring no complex configuration for immediate deployment.
Robust Build Quality – Industrial-grade design with IP20 protection rating, suitable for standard control cabinet environments .
Wide Operating Temperature Range – Reliable operation across diverse industrial environments, from 0°C to 55°C (or extended ranges per specific configurations) .
Company Overview – PLC EXPORT
The company has always adhered to its founding principles: quality first, high reliability, and excellent customer service, as its motto states: "We help keep global production running smoothly." With a dedicated team of over 50 employees and an outstanding track record, the company is poised to continue growing and making a more profound impact on the automation industry.
Typical Applications
ABB Advant OCS Bus Endpoint Termination – Installed on the bus connector when the main controller is located at the Profibus-DP bus endpoint, providing necessary terminal resistance for proper network termination .
Legacy DCS System Maintenance – Used for troubleshooting, repair, and spare part replacement in aging ABB distributed control systems, extending operational life without complete system overhaul .
Profibus-DP Network Expansion – Supports system expansion projects by ensuring proper bus termination when adding new segments or devices to existing Profibus-DP networks.
Communication Issue Resolution – Deployed as a solution for Profibus-DP bus communication fluctuations, bit errors, data loss, and network interruptions caused by improper termination .
System 800xA Legacy Platform Support – Compatible with the older System 800xA platform bus systems, providing critical spare parts for ongoing operations
