CI851K01 Overview
CI851K01 is an ABB AC 800M PROFIBUS DP Master Class I interface kit. It connects a compatible AC 800M controller to a PROFIBUS DP segment through the TP851 baseplate and DB9 connector. This interface is not for AC 800M High Integrity controller use.
Technical and Ordering Information
| Protocol | PROFIBUS DP |
|---|---|
| Master class | Class I |
| Communication speed | 9.6 kbit/s to 12 Mbit/s |
| Nodes | Maximum 32 per segment |
| Connector | DB9 female on TP851 |
| Galvanic isolation | Yes |
| CEX power | 24 V DC, 150 mA typical |
| Power dissipation | 3.6 W |
| Protection | IP20 |
| Warranty | 1 year |
Buyer and Engineering Checks
- Confirm a non-high-integrity AC 800M controller and CI851K01/TP851 architecture.
- Check node count, bus speed, DP addressing, cable and termination.
- Match installed controller software and the complete DP network configuration.
Quotation Support
Send CI851K01, quantity and destination for current stock, condition, packing and delivery confirmation.
